Part No.: GP-T448-8P

8-Core Fiber Floor Box

8-Core Fiber Floor Box

The GP-T448-8P Fiber Optic Floor Terminal Box is designed for installation on each level of a multi-dwelling unit (MDU) building, serving as a transition point between riser and horizontal cables in fiber-to-the-home (FTTH) applications. It provides flexibility for operators by offering storage for both over-length and terminated fibers, as well as acting as a splice point.

Specification

Dimension (WxHxD): 103x133x30mm

Inlet / Outlet: 2 / 12

Branch (Blind) ports: -

Splicing capacity: 6 / 12 FO

Patching capacity: 8 SC Adapter

Suitable splitter: -

Packing List

Carton Size: 61x43x29CM

Pieces per Carton: 50PCS/CTN

Download File
Request for Quotation View full details

  • Description

    The GP-T448-8P is a versatile and compact FTTH termination box that provides reliable protection and management for fiber optic connections. With a capacity of up to 12 fiber splices per tray and support for 8 SC adapters, the box is perfect for small-scale indoor fiber deployments. The high-strength plastic construction ensures durability, while the stackable splice tray design allows for easy access and maintenance, flipping 90 degrees when opened. The GP-T448-8P also accommodates a micro PLC splitter (1:8), making it an efficient solution for fiber distribution in FTTH applications.

  • Feature & Benifits

    Port capacities of the 8-Core Fiber Floor Box:
    • Splicing capacity: 6 / 12 FO
    • Patching capacity: 8 SC Adapter
    • Splitter capacity: -
    Key features for the 8-Core Fiber Floor Box:
    • Durable Construction: Made from high-strength, ultra-high-viscosity plastic for a strong and attractive design.
    • Easy Maintenance: Stackable splice trays that flip 90° for easy installation and maintenance.
    • High Capacity: Supports up to 12 fiber splices per tray and accommodates 8 SC adapters for efficient fiber management.
    • Compact Design: Ideal for indoor wall-mounted or cabinet installations, providing a space-saving solution for FTTH projects.
    • Micro PLC Splitter Support: Designed to accommodate 1x8 micro PLC splitters in the splice tray for enhanced fiber distribution.

Specifications

Part No. GP-T448-8P
Color Black / White / Gray / Light Gray
Dimension 103x133x30mm
Material of Housing ABS or PC/ABS
Protection class IP IP43
Main Cable Ports 2
Branch Cable Ports -
Drop Cable Ports 12
Fusion Splice 6 / 12 FO
Number of Splice Tray 1
Suitable Splitter -
Number of Adapters 8 SC Adapter
Mount Way Wall-mounted
