Part No.: FAT-10B-2

10 Ports Fiber Access Terminal Box

10 Ports Fiber Access Terminal Box

The FAT-10B-2 Fiber Access Terminal Enclosure is designed to streamline fiber optic connections at user access points in FTTX networks. It ensures quick and reliable connections by integrating cable splicing, fixation, and distribution into one unit. Suitable for both indoor and outdoor applications, the enclosure can be installed on walls or poles, ideal for setups requiring IP68-rated protection.

Specification

Dimension (WxHxD): 210x210x85 mm

Inlet: 1 Hardened Adapter

Terminal Capacity: 9 Hardened Adapter

Splicing capacity: 2/4 F

Suitable splitter: Micro splitter 1:8, uneven splitter 1:9

Packing List

Carton Size: 56x46x60CM

PCS/CTN: 20 PCS/CTN

Download File
Request for Quotation View full details

  • Description

    The FAT-10B-2 Fiber Access Terminal Enclosure, outfitted with Hardened Adapters, offers a comprehensive fiber management system for connecting distribution and drop cables. Its IP68 waterproof rating ensures durability in harsh environments. The enclosure accommodates up to 10 ports, with 9 reserved for hardened adapters, facilitating quick connections without additional field terminations. Constructed from high-quality PC/ABS materials, it supports both micro and non-standard PLC splitters and maintains control over the fiber bending radius to maintain signal integrity, thus improving the efficiency of installations in fiber optic networks.

  • Feature & Benifits

    Port capacities of the 10 Ports Fiber Access Terminal Box:
    • Terminal capacity: 9 Hardened Adapter
    • Splitter capacity: Micro splitter 1:8, uneven splitter 1:9
    Key features for the 10 Ports Fiber Access Terminal Box:
    • High Protection Level: IP68-rated enclosure suitable for outdoor wall or pole mount installation.
    • Integrated Cable Management: Includes splice slot and cable management system to organize fibers.
    • Efficient Connectivity: Supports 9 hardened adapters and 1 hardened inlet, allowing fast connections.
    • Mounting Flexibility: Suitable for both wall and pole mounting for versatile installation options.
    • Material Durability: Constructed from robust PC/ABS material to withstand environmental stress.
    • Splitter Compatibility: Supports 1:8 micro splitter and 1:9 uneven splitter for flexible network configurations.

General Specifications

Part No. FAT-10B-2
Color Black / Gray / Light Gray
Dimension 210x210x85 mm
Material of Housing PC/ABS
Protection class IP IP68
Cable Inlet 1 Hardened Adapter
Branches
Terminal Capacity 9 Hardened Adapter
Fusion Splice 2/4 F
Number of Splice Tray -
Suitable Splitter Micro splitter 1:8, uneven splitter 1:9
Number of Adapters 10 SC
Mount Way Wall / Pole Mounted
