Part No.: GJS-H1203

Mini Fiber Optic Splice Closure | GJS-H1203

Mini Fiber Optic Splice Closure | GJS-H1203

Specification

Dimension (WxHxD): 178 × 117 × 22.5 mm

Inlet / Outlet: 3 / N/A

Branch (Blind) ports: N/A

Splicing capacity: 2/4 fusion splices

Patching capacity: N/A

Suitable splitter: N/A

Collapsible row

Carton Size: 54.5*40.0*25.5CM

PCS/CTN: 64 PCS/CTN

Download File
Request for Quotation View full details

  • Description

    The GJS-H1203 is an in-line type mini fiber optic splice closure, designed for FTTx networks. It accommodates up to 4 fusion splices and 3 cable ports. The closure is suitable for deployment in aerial, wall-mounted applications.

  • Feature & Benifits

    Port capacities of the Mini Fiber Optic Splice Closure | GJS-H1203:
    • Splicing capacity: 2/4 fusion splices
    • Patching capacity: N/A
    • Splitter capacity: N/A
    Key features for the Mini Fiber Optic Splice Closure | GJS-H1203:
    • Compact size, Mini closure.
    • Rubber grommet is re-useable.
    • Wall mounted or aerial mounted.

General Specifications

Part No. GJS-H1203
Color Black (Customizable)
Dimension 178 × 117 × 22.5 mm
Material of Housing MPP
Protection class IP IP68
Main Cable Ports 3
Branch Cable Port N/A
Drop Cable Ports N/A
Fusion Splice 2/4 fusion splices
Number of Splice Tray N/A
Suitable Splitter N/A
Number of Adapters N/A
Mount Way Aerial / Wall-mounted
